WZ-580C SMD BGA Rework Station Machine
Product Overview
A populated board that fails final test does not have to end up in the reject bin. This listing covers the WZ-580C SMD BGA rework station — printed on the page as PCB line machine SMD BGA rework station machine — a bench machine for working on a single assembled board. The attribute table hands you the whole working envelope up front: boards from 10 x 10 mm up to 400 x 370 mm, BGA chips from 1 x 1 mm up to 60 x 60 mm, board thickness 0.3-5 mm, supply AC 220V ±10% 50Hz, total power 4800W to 6800W, and a machine weight of 40 kg. Nothing beyond those fields is printed on this page, so we ask you rather than assume anything on your behalf. Send the board and the part you need to work on, and the unit gets checked against your job.
Board Fit Check
- Board from 10 x 10 mm to 400 x 370 mm — inside the envelope the PCB size field states.
- BGA chip from 1 x 1 mm to 60 x 60 mm — inside the range the chip field gives.
- Board thickness 0.3-5 mm — matches the thickness field as printed.
- Any figure outside those three ranges — pass the measurement over and we will state whether this model covers your job, rather than leaving you to guess.
- Supply on site: AC 220V ±10% 50Hz; total power drawn between 4800W and 6800W as the fields state.
Key Features
1. Model WZ-580C — the model field as listed.
2. PCB Size Range — min 10 x 10 mm, max 400 x 370 mm, both from the size field.
3. BGA Chip Size Range — min 1 x 1 mm, max 60 x 60 mm, both from the chip field.
4. PCB Thickness 0.3-5 mm — the thickness field as printed.
5. Power AC 220V ±10% 50Hz — the supply field.
6. Total Power 4800W to 6800W — the total power field, a range exactly as listed.
7. Machine Weight 40 kg — the weight field.
8. Single-Board Rework Unit — positioned on the page as an SMD BGA rework station machine.
Technical Specifications
Product name: PCB line machine SMD BGA rework station machine
Model: WZ-580C
PCB size: max 400 x 370 mm / min 10 x 10 mm
BGA chip size: max 60 x 60 mm / min 1 x 1 mm
PCB thickness: 0.3-5 mm
Power: AC 220V ±10% 50Hz
Total power: 4800W to 6800W
Weight of machine: 40 kg
Before You Order
- Several items a bench unit is normally chosen on carry no values in the attributes here. If your process depends on those, put your requirement in the message and we will come back with the confirmed data for this model.
- No nozzle, tip or other consumable is listed together with this machine. Tell us what your job needs and we will advise what can be supplied — our separate nozzle listings cover other brands if that is what you are after.
- Board support and tooling for your particular assembly are not described here. Share the board drawing and the parts to be worked on, and fitment gets confirmed ahead of any order.
| WZ-580 | WZ-620 | WZ-650 | WZ-750 | |
| Power | AC 220V±10% 50Hz | AC 220V±10％ 50/60Hz | AC 110V / 220V±10% 50/60Hz | AC 110V / 220V±10% 50/60Hz |
| Overall dimension | L500mm*W590mm*H650mm | L650*W630*H850mm | L 600*W 640*H 850mm | L830*W670*H850mm |
| PCB size | Max 400mm*370mm Min 10mm*10mm | Max 450*390mm Min 10*10 mm | Max 400mm*370mm Min 10mm*10mm | MAX 550*480mm MIN 10*10mm( customizable ) |
| BGA chip size | Max 60mm*60mm Min 1mm*1mm | Max 60mm*60mm Min 1mm*1mm | MAX 70*70mm -MIN 1*1 mm | Max 60mm*60mm Min 1mm*1mm |
| PCB thickness | 0.3-5mm | 0.3-5mm | 0.3 - 5mm | 0.5-8mm |
| Weight of machine | 40KG | 60kg | 60KG | 90kg |
| Warranty | 1 year | 1 year | 1 year | 1 year |
| Total power | 4800W | 5300w | 6400W | 6800W |
| Usage | Repair chips / phone motherboard etc | Repair chips / phone motherboard etc | Repair chips / phone motherboard etc | Repair chips / phone motherboard etc |
| Electrical material | Touch screen+Temperature control module+PLC control | Driving motor+PLC smart temp.controller+color touch screen | Driving motor + smart temp. controller + color touch screen | Touch screen+Temperature control module+PLC control |
| Location way | V-shape card slot+Universal jigs | V-shape card slot+Universal jigs | V-shape card slot+Universal jigs | V-shape card slot+Universal jigs |
