34764 134765 140135 DEK Calibration PCB board Calibration TOOL

The calibration board 134765 and board plate 140403 ensure that the printer’s vision system is accurately aligned with the printing area. This alignment is crucial to prevent the misplacement of components and ensure precise printing.

The calibration board helps in achieving optimal registration between the stencil and the PCB. This is essential to ensure that solder paste or other materials are deposited precisely onto the intended locations on the board.

using the DEK Calibration Board 134765 and board plate 140403, you can fine-tune the printer’s vision system. This includes adjusting lighting, focus, and image processing parameters to improve the accuracy of component placement.

correct calibration minimizes defects due to misalignment or incorrect registration. This reduces rework and improves the overall quality and reliability of printed circuit boards.

The calibration board plays a pivotal role in maintaining consistency throughout the production process. It ensures that each board receives the same level of accuracy and alignment, resulting in uniform product quality.
