SMT Pick And Place Machine SAMSUNG SM481plus SM482plus SM471plus
Name:Samsung SM481plus SM482plus SM471plus
Brand:SAMSUNG
Model:SAMSUNG SM481plus SM482plus SM471plus
Specification:SMT PICK AND PLACE MACHINE
Condition:original
Quality:top qualiy
Stock:large
Payment:T/T before shipment
Shipment:on-time shipment
Warranty: 1 year
Delivery:fedex,ups,dhl,as required
Package:wooden case
| Model Name | SM471plus | SM481plus | SM482plus |
| Spindles | 10 Spindles ×2 Gantry | 10 Spindles ×1 Gantry | 6 Spindles ×1 Gantry |
| Placement Speed | 78,000CPH(Optimum) | 40,000CPH(Optimum) | 30,000CPH(Optimum) |
| Placement Accuracy | ±50μm@μ±3σ | ±30μm@μ±3σ | ±30μm@μ±3σ |
| Applicable Parts | 0402 ~ 14mm(H 12mm) | 0402 ~ 42mm(H15mm) | 0402 ~ 55mm(H 15mm) |
Applicable PCB | Max. 510(L) x 460(W)(Standard) | Max. 460(L) x400(W)(Standard) | Max. 460(L) x400(W)(Standard) |
| Max. 610(L) x 460(W)(Option) | Max. 1500(L) x 460(W)(Option) | Max. 1200(L) x 510(W)(Option) | |
| Dimension(mm) | 1650×1690×1458 | 1650×1680×1530 | 1650×1680×1458 |
The SM482PLUS can perform high-speed placement of chips at 40,000CPH and QFPs at one per 1.1 seconds,
respectively (each at optimum speed) by applying the on-the-fly recognition technology patented by Techwin,
which enables component placement at the highest speed among all medium speed component placers.
With one-gantry structure having a high-speed piano head with 10 nozzles,
the machine can be operated with minimum manpower using one side of the machine.
Being able to produce long boards with lengths of up to 1,500mm,
the machine boasts of its applicability to the largest PCBs among SM series component placers.
