Panasert AM100 Special Nozzle SMT Pick and Place Part

Panasert AM100 Special Nozzle SMT Pick and Place Part

About This Panasert AM100 Special SMT Nozzle

This is a special nozzle for Panasert and Panasonic placement machines - the tip that is used when a standard round nozzle will not hold the part being placed. It is listed for the AM100, and the range covers the CM, MV and MSF machine families as well, so the lists below are what a buyer works from when a nozzle has to be matched to a machine that is already on the floor.

Three lists cover the range: the MV series nozzles with the figures recorded against each one, the MSF and CM items by part number and type, and the part numbers for the CM202, CM402, CM212, CM602 and DT401 machines.

Listing Specifications & Nozzle Parameters

- Product Name: PANASERT SMT MACHINE AM100 SPECIALNOZZLE

- Model Number: AM100 SPECIAL NOZZLE

- Part No: AM100 SPECIAL NOZZLE

- Type: SMT Machine Parts

- Brand: ODM

- Condition: New, Original

- Quality: Top

- Package: Foam Package+Plastic BOX+Carton Box

- Port: Shenzhen

- Delivery: Ups,dhl,fedex,as Your Order

- Warranty: 1 Month

- Stock: large

- Payment: T/T before shipment

- Shipment: on-time shipment

Odd-Form Component Handling & Custom Nozzle Features

A standard nozzle picks a part by vacuum through a round tip, which is fine for a chip and no use at all for a shield, a connector body or a part whose top face is not flat. That is the gap this range fills: the tip is shaped for the component instead of the component being chosen to suit the tip.

The lists show what that shaping looks like in practice. MV nozzles appear with a reflector and without one, and one of them carries a cup. There are tapered tips and MELF tips at several sizes, large LL and LLL tips, and a gripper type with a reflector for parts that have to be held rather than drawn up. For the smallest work, two CM-602 numbers are listed for 01005 and 0201 components.

Where a part is not covered by any of those, a nozzle can be made to suit it. Send a drawing of the tip that is needed, or a photo of the component with its dimensions and the machine it will run on, and the tip is quoted against that.

Complete Machine Series & Cross-Model Part Number Reference

MV series nozzles:

- 0179484K PANASERT MV NOZZLE WITH REFLECTOR N/A 0.50 mm

- 0179380K PANASERT MV NOZZLE WITH REFLECTOR N/A 0.80 mm

- 0179381K PANASERT MV NOZZLE WITH REFLECTOR N/A 1.20 mm

- 0106016K PANASERT MV NOZZLE WITHOUT REFLECTOR 1.60 mm 1.20 mm

- 1020179065 PANASERT MV NOZZLE N/A 4.00 mm 3.00 mm

- 1020179065-U6.10 PANASERT MV NOZZLE WITH CUP 4.00 mm N/A

- 102247902201 PANASERT MV NOZZLE LL 8.00 mm N/A

- 10201062304 PANASERT MV NOZZLE LLL 8.00 mm N/A

- 0175015K09 PANASERT MV NOZZLE TAPERED 0.80 mm 0.50 mm

- 0153001K PANASERT MV NOZZLE MELF 1.20 mm 0.80 mm

- 0153031K PANASERT MV NOZZLE MELF 1.60 mm 1.20 mm

- 0106016K/MELF PANASERT MV NOZZLE MELF 2.00 mm 1.60 mm

- 102017950001 PANASERT MV NOZZLE N/A 3.00 mm 2.00 m

Quality Standards, Custom Sizing & Protective Packaging

Top is the value recorded for quality here, and the condition is given as new and original. Packing runs to a foam layer, a plastic box and a carton box, and shipment is by UPS, DHL or FedEx as the order requires. Payment is listed as T/T before shipment.

Line up the part number you want against the three lists before enquiring. If the tip is not in any of them, the size comes from the component rather than from a catalogue, so the drawing or the component itself is what starts the order.

Frequently Asked Questions On Panasert Special Nozzles

Q1: Which machines do these nozzles cover?

A: The AM100, and the CM, MV and MSF families shown above, including CM-202, CM-402 and CM-602 and the CM202, CM402, CM212, CM602 and DT401 part number list.

Q2: What are special nozzles used for?

A: Parts that a round tip will not hold reliably - shields, connector bodies, MELF parts, and the 01005 and 0201 components.

Q3: Can a nozzle be made to my drawing?

A: Yes. Send the drawing, or the component with its dimensions, together with the machine model.

Q4: Are there nozzles for 01005 and 0201 parts?

A: Two CM-602 numbers are listed for those components.

Q5: Is there a gripper type?

A: Yes. The CM-202/CM-402 list includes a gripper with reflector.

Q6: How are the nozzles packed and sent?

A: A foam layer, a plastic box and a carton box, with shipping arranged on UPS, DHL or FedEx.

Custom Sourcing & Nozzle Inquiry Assistance

- Company: WEN ZHAN Technology

- Tel / WhatsApp: +86 18823383970

- E-mail: wenzhanhucai@163.com

Send the machine model, the nozzle type or part number, and the quantity, and the tip is confirmed with the price.
