WZ-580C 620C 650C 750C SMD BGA Rework Station Machine
Product Overview
Rebuilding a failed assembly is workshop work, and the tool for it is chosen by fit before anything else. What this listing puts forward is a family rather than one machine: the model field names WZ-580C, WZ-620C, WZ-650C and WZ-750C on a single line, and the eight attributes beneath them describe the bench station that bears those model numbers. The whole working envelope — board and chip limits, thickness, supply, power draw and machine weight — is set out in the specification block, given once for the group rather than divided between the four numbers. How the four numbers differ is not set out anywhere on the page, and we will not manufacture a split that the maker has not published — ask us and the answer is obtained for you.
The Four Models on This Listing
- WZ-580C, WZ-620C, WZ-650C and WZ-750C all appear in the model field, side by side.
- One set of figures is published, not four: size, chip, thickness, supply, power and weight are stated once for the group.
- Because of that, picking a model is a conversation rather than a table lookup — give us the board you handle and the operation you perform, and the model number is settled against it.
Key Features
1. Family of Four Model Numbers — the model field groups WZ-580C, WZ-620C, WZ-650C and WZ-750C.
2. Single Shared Figure Set — the listed values apply to the group and are not divided between the numbers.
3. Working Envelope Published In Full — board and chip limits, thickness, supply, power draw and machine weight are all set out in the specification block.
4. Bench-Scale Rework — the listing positions the unit for single-board SMD and BGA work.
5. Selection Support — the model number for your job is settled by describing the assembly and the operation.
6. No Per-Model Split Claimed — the page states no difference between the four numbers, and none is added here.
7. Consumables Guidance — what your process consumes can be sourced on request, and nozzle lines for other brands are held separately.
8. Written Quotation Basis — the figures confirmed for your model number are the ones put to you in writing.
9. Open Questions Welcome — anything the attributes leave unanswered is obtained from the maker's data rather than assumed.
Technical Specifications
Product name: PCB line machine SMD BGA rework station machine
Model: WZ-580C / WZ-620C / WZ-650C / WZ-750C
PCB size: max 400 x 370 mm / min 10 x 10 mm
BGA chip size: max 60 x 60 mm / min 1 x 1 mm
PCB thickness: 0.3-5 mm
Power: AC 220V ±10% 50Hz
Total power: 4800W to 6800W
Weight of machine: 40 kg
Notes Before Ordering
- A per-model breakdown is not part of this page. If you need the numbers for one model number rather than the group, ask for it and we will request the individual figures.
- Process-side data is likewise absent — nothing on how the station is heated or controlled, and no measurement figure. We supply the maker's answer rather than a plausible one.
- No consumable is supplied with this listing. Describe what your operation consumes and we will report what can be sourced; our nozzle lines cover other brands.
| WZ-580 | WZ-620 | WZ-650 | WZ-750 | |
| Power | AC 220V±10% 50Hz | AC 220V±10％ 50/60Hz | AC 110V / 220V±10% 50/60Hz | AC 110V / 220V±10% 50/60Hz |
| Overall dimension | L500mm*W590mm*H650mm | L650*W630*H850mm | L 600*W 640*H 850mm | L830*W670*H850mm |
| PCB size | Max 400mm*370mm Min 10mm*10mm | Max 450*390mm Min 10*10 mm | Max 400mm*370mm Min 10mm*10mm | MAX 550*480mm MIN 10*10mm( customizable ) |
| BGA chip size | Max 60mm*60mm Min 1mm*1mm | Max 60mm*60mm Min 1mm*1mm | MAX 70*70mm -MIN 1*1 mm | Max 60mm*60mm Min 1mm*1mm |
| PCB thickness | 0.3-5mm | 0.3-5mm | 0.3 - 5mm | 0.5-8mm |
| Weight of machine | 40KG | 60kg | 60KG | 90kg |
| Warranty | 1 year | 1 year | 1 year | 1 year |
| Total power | 4800W | 5300w | 6400W | 6800W |
| Usage | Repair chips / phone motherboard etc | Repair chips / phone motherboard etc | Repair chips / phone motherboard etc | Repair chips / phone motherboard etc |
| Electrical material | Touch screen+Temperature control module+PLC control | Driving motor+PLC smart temp.controller+color touch screen | Driving motor + smart temp. controller + color touch screen | Touch screen+Temperature control module+PLC control |
| Location way | V-shape card slot+Universal jigs | V-shape card slot+Universal jigs | V-shape card slot+Universal jigs | V-shape card slot+Universal jigs |
Why Choose WEN ZHAN Technology
A model family is only useful when somebody explains it. WEN ZHAN Technology has spent more than twenty years equipping SMT workshops and their bench positions, and that is why the range is shown here rather than a lone part code: describe the assembly and the operation to be done, and the member of the family that suits it is identified, its figures confirmed against the maker's data, and the details forwarded for your approval.
FAQ
Q1: Why are four model numbers shown on this page?
A: The model field carries WZ-580C, WZ-620C, WZ-650C and WZ-750C together, and the listing publishes no split between them.
Q2: How do I know which of the four to take?
A: Your board and your operation decide it, not the page. Tell us both and we will identify the number that suits the work.
Q3: Are individual specifications given for each model?
A: They are not separated here — size, chip, thickness, supply, power and weight stand as one set of values.
Q4: What board dimensions does the listing cover?
A: A minimum of 10 x 10 mm and a maximum of 400 x 370 mm, per the size field.
Q5: What chip dimensions are covered?
A: 1 x 1 mm at the lower end and 60 x 60 mm at the upper end, from the chip field.
Q6: Which thickness range is written on the page?
A: 0.3 mm through 5 mm.
Q7: What must the workshop supply provide?
A: AC 220V ±10% 50Hz, with the total power stated as a span of 4800W to 6800W.
Q8: What does the machine weigh?
A: The weight attribute gives 40 kg.
Q9: Can I obtain per-model data before deciding?
A: Yes. Ask for it and the individual figures are requested from the maker instead of being filled in from assumption.
