Samsung SMT Solenoid Valve VA01PEP34A-1U VA01PEP34B-1U
About This Samsung SMT Solenoid Valve Pair
Two valve numbers are covered here, VA01PEP34A-1U and VA01PEP34B-1U, both of them pneumatic solenoid valves listed for Samsung SM series placement machines and both quoted for the same machine family.
The valve is the small switching part in the head's air circuit. It is what changes the head between holding a component against the nozzle tip and letting it go, so when a valve stops switching cleanly the symptom shows up at the nozzle rather than at the valve: a part that is picked and then dropped on the way to the board, or a nozzle that keeps hold of a component after it has been placed.
This is the valve sold as a spare part. Condition, packing and the rest of the listing details are set out below, and where a valve is being matched against a machine that is already running, the marking on the valve being replaced and the machine model are what settle the fit.
Key Specifications & Valve Listing Details
- Condition: New
- Type: SMT Machine Part
- Package: Standard Package
- Delivery: DHL/FEDEX/UPS
- Stock: Large
- Shipment: On-time Shipment
Description details:
- Model: Samsung SM machine solenoid valve
- Payment: full payment before shipment
- Package: Standard carton box with foam
- After-sale service: Video technical support, online support
Pneumatic Control Role & Machine Head Compatibility
Both numbers are listed for the SM series. In the head's air circuit the valve handles the changeover between drawing a component against the nozzle tip and releasing it again, which is the part of the placement cycle it carries.
Which of the two numbers goes in a given position is settled against the machine's parts list, or against the marking on the valve that is being taken off the head. Send a photo of the valve body together with the machine model and that match is confirmed before an order is placed.
The page does not record the coil voltage, the port thread, the working pressure range or the material of the body, so none of those are stated in this description. Read them from the old valve, or send the photo and the model, and the figures are confirmed against your machine.
Valve Body Inspection, Quality Testing & Packaging
The valves are offered new, as SMT machine parts, and stock is listed as large. Each one travels in a standard carton with foam, which is what a small pneumatic part needs if it is to arrive without a marked body or a bent spigot, and shipping is on DHL, FedEx or UPS. Payment is full payment before shipment.
After-sale service on this number covers video technical support and online support, so a question that comes up during fitting can be talked through with someone rather than left to guesswork at the machine.
Frequently Asked Questions On SMT Solenoid Valves
Q1: Which machines are these valves listed for?
A: Both numbers are listed for Samsung SM series placement machines.
Q2: Which number should I order, A or B?
A: Both are listed for the SM series. The position each number goes in is confirmed against your machine's parts list or the marking on the valve being replaced.
Q3: What does the valve do in the machine?
A: It switches the head's air between holding a component against the nozzle tip and releasing it.
Q4: Can you give me the coil voltage or the port thread?
A: Those are not recorded on this number. Read them from the old valve, or send a photo with the machine model, and they are confirmed against your machine.
Q5: What points to a valve that needs replacing?
A: A component picked and then dropped before placement, or a nozzle that will not release a component after it has been placed.
Q6: How are the valves packed and sent?
A: A standard carton with foam, sent on DHL, FedEx or UPS.
Order Inquiry & Pneumatic Parts Sourcing Support
- Company: WEN ZHAN Technology
- Tel / WhatsApp: +86 18823383970
- E-mail: wenzhanhucai@163.com
Send the machine model, the valve part number and the quantity, and the match is confirmed with the price.
