| Specifications | YAMAHA Pick and Place Machine |
|---|---|
| Applicable PCB | L 510 x W 460mm - L 50 x W 50mm* Option: Up to L610 mm available |
| Mounting capability | 46,000CPH (The Company's optimum conditions) |
| Applicable components | 03015-W 55 x L 100mm (divided recognition for over W 45mm), H: 15mm or less |
| Mounting accuracy | ±0.035 mm (±0.025 mm) Cpk≧1.0 (3σ) |
| Number of component types | Setting Plate : Max 96 types (8mm)Tray : 15 types (sATS 15 equipment) |
| Power supply | 3-phase AC 200/208/220/240/380/400/416 V ±10% 50/60 Hz |
| Air supply source | 0.45MPa or more, clean and dry state |
| External dimension | L 1,254 x W 1,440 x H 1,445mm (excluding protrusions) |
| Weight | 1,270kg |
| yamaha machine | |||
|---|---|---|---|
| Model | YSM10 | YS12 | YS24 |
| Applicable PCB | L 510 x W 460mm - L 50 x W 50mm | L510x~W460mm to L50x~W50mm | L50mm x W50mm to L700mm x W460mm |
| Mounting Capability | 46,000CPH | 36,000CPH | 72,000CPH |
| Mounting Accuracy | ±0.035 mm (±0.025 mm) Cpk>1.0 (3σ) | +/-0.05mm/CHIP | +/-0.05mm (μ + 3σ), +/-0.03mm (3σ) |
| Number of component types | 15 types (sATS 15 equipment, Max, JEDEC) | 120 types(Max, 8mm tape reel conversion) | 120 types (Max./8mm wide tape reel conversion) |
| Applicable components | 03015-W 55 x L 100mm, H: 15mm or less | 0402(Metric base) to 32*mm components | 0402 to 32x32mm MAX (Height 6.5mm or less) |
| External Dimensions | L 1,254 x W 1,440 x H 1,445mm | L 1,254 x W 1,440 x H 1,445mm | L1,254x W1,687x H1,445mm |
