6 Zone SMT Reflow Oven for PCBA Production
What The Listing States
This page covers a six-zone SMT reflow oven, described in its usage field as an automatic conveying convection reflow oven for SMT PCBA production. Six attributes make up the whole record: a certification entry, the supply voltage, that usage wording, a current figure, and a warranty term of one year. Two promotional words sit in the listing title, and no attribute supports either of them, so neither is repeated in this text. Process detail — the way the oven behaves on a board — is outside the record as well; ask, and the machine's own data answers.
| MODEL | WZ-8820PC-LF | WZ-8810PC/LS-LF | WZ-8830PC/LS-LF |
|---|---|---|---|
| Dimension | 5000*1200*1550mm | 4600*1000*1550mm | 4600*1500*1550mm |
| Weight | 1800kg | 1200kg | 1600kg |
| Number of heating zone | Top 8/Bottom 8 | ||
| Length of heating zone | 3160mm | 2800mm | 2800mm |
| Cooling quantity | Up 2/Bottom 2 | Up 1/Bottom 1 | Up 1/Bottom 1 |
| Air discharge requirement | 10m³/min*2 | ||
| Power requirements | 3 phase 380V 50/60Hz | ||
| Starting power | 36KW | 32KW | 48KW |
| Operating power | 7KW | 6.5KW | 8KW |
| Heating time | Approx: 20min | ||
| Temperature control range | Room temp-320°C | ||
| Temperature control Mode | PID closed-loop control with SSR drive (computer + PLC) | ||
| Temperature control precision | ±1°C | ||
| Temperature deviation On PCB | ± 2°C | ||
| Abnormal alarm | Ultra high temperature or low temperature alarm | ||
| Maximum width of PCB | 50-500mm | 50-450mm | 50-600/700/800mm |
| Guide rail width range | 50-400mm | 50-370mm | 50-500/600/700mm |
| PCB element height | Top 30mm Bottom 25mm | ||
| Transportation direction | L-R (Option: R-L) | ||
| Transportation speed | 0-1800mm/min | ||
| Transportation height | 900±20mm | ||
| Transport guide rail fixation | Front end fixed (Option: Back end fixed) | ||
| Cooling mode | Force wind cooling | ||
| PCB transport mode | Chain +Ribbon | Chain (Chain optional) | Chain (Chain optional) |
Purchase Conditions At A Glance
- Certification: the field lists CE and ISO. That is the value as printed, and it is not enlarged here into a statement about testing, compliance or paperwork.
- Warranty: one year, as the listing carries it; nothing longer is claimed.
- Supply voltage: AC220V, in the form the field gives it.
- Usage: an automatic conveying convection reflow oven for SMT PCBA production, as worded on the page.
- Configuration: six zones, named in the product title.
- Current: the listing prints a figure that does not stand up as an electrical unit, so it is left out of this text and put to the maker for confirmation.
The Six Attributes
Product name: SMT 6 zones reflow oven
Certification: CE, ISO
Voltage: AC220V
Usage: Automatic conveying convection reflow oven for SMT PCBA production
Warranty: 1 year
Points To Settle With Us
- The listing's own product title opens with a bargain word. That word is not used on this page, and the field itself is worth correcting in the back end; the configuration it describes is the six-zone one.
- Two further words in the listing title carry an application and a size impression, and neither has a matching field in the attributes. Neither is turned into a claim here; send us the boards you run and the space you have, and the configuration is checked against both.
- What the oven does in process terms is not published at all. Nothing is invented to fill that space — set out your requirement and the figures come from the machine's record.
- The certification entry is a field value. Which standard each mark refers to, and what documentation travels with a unit, is confirmed with the maker rather than inferred from the field.
- The current figure is not repeated in this text, as noted above; it goes to the maker for confirmation.
- State, packing and dispatch are three subjects the attributes simply do not cover; all three are handled with the offer rather than stated here.
About Our Supply Record
A purchase decision rests on terms that can be checked. More than two decades of SMT equipment supply sit behind WEN ZHAN Technology, so the terms this page can stand behind are set out plainly and the ones it cannot are left for confirmation: give us the configuration and the terms your purchase needs, and the unit's particulars, plus whatever paperwork applies, are put in front of you before you commit.
Answers To Common Enquiries
Q1: What is the machine on this page?
A: A six-zone SMT reflow oven, described in the usage field as an automatic conveying convection unit for SMT PCBA production.
Q2: Which certifications are stated?
A: The certification field reads CE and ISO — the field value as the listing prints it.
Q3: Does that settle which standard the unit meets?
A: The field states two marks and nothing beyond them. The standard each mark refers to, and the paperwork a unit travels with, is confirmed with the maker.
Q4: What supply does it need?
A: AC220V, in the form the voltage field gives it.
Q5: What does the current field say?
A: It prints a figure that does not hold as an electrical unit, so it is not repeated on this page; the maker is asked to confirm it.
Q6: What warranty applies?
A: One year, as the listing carries it.
Q7: How many zones does the oven have?
A: Six, as the product title states.
Q8: Will it suit display-board work, or a position where space is tight?
A: The listing title carries an application word and a size word, and no attribute backs either. Rather than repeat them, tell us your boards and the room available and the fit is checked for you.
Q9: Can the unit's details be seen before we order?
A: Yes — pictures of the actual machine and its identification particulars can be sent on request, before you decide anything.
How To Reach Us
- Company: WEN ZHAN Technology
- Tel / WhatsApp: +86 18823383970
- E-mail: wenzhanhucai@163.com
Send the configuration you need and the terms your purchase requires — we will confirm what the unit carries and what paperwork comes with it.
