Home > products > Samsung Chip Mounter > SMT Machine Hanwha Samsung SM481plus Pick And Place Machine

SMT Machine Hanwha Samsung SM481plus Pick And Place Machine

Product Details

Brand Name: SAMSUNG/ HANWHA

Model Number: SM411 SM481 SM482 SM471

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: Negotiable

Packaging Details: 1.Wooden case and vacuum package 2.As your requirements

Delivery Time: 5-8 days

Payment Terms: T/T, Western Union, Paypal, Credit card

Supply Ability: 5000

Get Best Price
Highlight:

40000CPH SMT Pick And Place Machine

,

SM481plus SMT Pick And Place Machine

,

SM481plus pick and place pcb machine

Name:
Samsung SM411 SM481 SM482 SM471
Brand:
SAMSUNG HANWHA
Model:
SM411 SM481 SM482 SM471
Specification:
SMT PICK AND PLACE MACHINE
Condition:
New And Used
Quality:
Top Qualiy
Stock:
Large
Payment:
Payment
Shipment:
On-time Shipment
Warranty:
1 Year
Delivery:
Fedex,ups,dhl,as Required
Package:
Wooden Case
Name:
Samsung SM411 SM481 SM482 SM471
Brand:
SAMSUNG HANWHA
Model:
SM411 SM481 SM482 SM471
Specification:
SMT PICK AND PLACE MACHINE
Condition:
New And Used
Quality:
Top Qualiy
Stock:
Large
Payment:
Payment
Shipment:
On-time Shipment
Warranty:
1 Year
Delivery:
Fedex,ups,dhl,as Required
Package:
Wooden Case
SMT Machine Hanwha Samsung SM481plus Pick And Place Machine

SAMSUNG SM411 SM481 SM482 SM471 CHIP Mounter

Name:Samsung SM411 SM481 SM482 SM471
Brand:SAMSUNG
Model:SAMSUNG SM411 SM481 SM482 SM471
Specification:SMT PICK AND PLACE MACHINE
Condition:original
Quality:top qualiy
Stock:large
Payment:T/T before shipment
Shipment:on-time shipment
Warranty: 1 year
Delivery:fedex,ups,dhl,as required
Package:wooden case



The SM481PLUS can perform high-speed placement of chips at 40,000CPH and QFPs at one per 1.1 seconds, respectively (each at optimum speed) by applying the on-the-fly recognition technology patented by Hanwha, which enables component placement at the highest speed among all medium speed component placers. With one-gantry structure having a high-speed piano head with 10 nozzles, the machine can be operated with minimum manpower using one side of the machine. Being able to produce long boards with lengths of up to 1,500mm, the machine boasts of its applicability to the largest PCBs among SM series component placers.



Main Features of Hanwha SMT Pick and Place Machine

1,Realizes a Super-high Speed Placement Speed of 40,000 CPH
Realizes the Highest Placement Speed Among Chip Shooters of the Same Class by Adopting a New Flying Head Mechanism Equipped With 10 Spindles.
2,Electrically Driven High Speed and High Precision Feeder
Electrically Driven SM Feeder
Allows integrated use of 0603/2P/4P Equipped with a function to automatically align the pickup position between feeders to improve the simultaneous pickup rate. Able to set various part supply speeds to improve the stability of part supply.
40,000 CPH(Optimum)
1 Gantry x 10 Spindles/Head
Applicable Parts : 0402 ~ 14mm(H 12mm)
Applicable PCB : Max. 460(L) x400(W)(Standard)
Max.510(L) x 460(W)(Option)
Electrically Driven High Speed and High Precision Feeder
Allows mixed use with an SM pneumatically driven feeder
SMART Feeder

The world’s first feeder equipped with Auto Splicing and Auto Loading functions



Model Name SM471plus SM481plus SM482plus
Spindles 10 Spindles ×2 Gantry 10 Spindles ×1 Gantry 6 Spindles ×1 Gantry
Placement Speed 78,000CPH(Optimum) 40,000CPH(Optimum) 30,000CPH(Optimum)
Placement Accuracy ±50μm@μ±3σ ±30μm@μ±3σ ±30μm@μ±3σ
Applicable Parts 0402 ~ 14mm(H 12mm) 0402 ~ 42mm(H15mm) 0402 ~ 55mm(H 15mm)



Applicable PCB

Max. 510(L) x 460(W)(Standard) Max. 460(L) x400(W)(Standard) Max. 460(L) x400(W)(Standard)
  Max. 610(L) x 460(W)(Option) Max. 1500(L) x 460(W)(Option) Max. 1200(L) x 510(W)(Option)
Dimension(mm) 1650×1690×1458 1650×1680×1530 1650×1680×1458



FAQ

1. If machine have any problem after I receive it, how can I do ?

Free parts send to you in machine warranty period.

2. MOQ ?

1 set machine, mixed order is also welcomed.

3. How can I buy this machine from you? ( Very easy and flexible !)

A. Consult us about this product on line or by e-mail.

B. Negotiate and confirm the final price , shipping , payment methods and other terms.

C. Send you the proforma invoice and confirm your order.

D. Make the payment according to the method put on proforma invoice.

E. We prepare for your order in terms of the proforma invoice after confirming your full payment.

And 100% quality check before shipping.

F.Send your order by air or by sea.
