This SMT assembly line provides integrated production solutions for PCB and LED light manufacturing, covering core processes including solder paste printing, component placement, reflow soldering and optical inspection. It is designed for commercial production scenarios, and supports configuration adjustment to match different production scales and product specifications. The line can be adapted to both newly built workshops and existing production line upgrades, helping enterprise customers establish complete surface mount production capacity.
The standard configuration of the SMT assembly line includes four core types of equipment to cover the main SMT production workflow. Chip mounters are responsible for picking and placing surface mount components onto PCB substrates. Reflow ovens complete the soldering process through controlled temperature curve heating. Automatic optical inspection (AOI) equipment performs post-soldering defect detection to ensure production yield. PCB printers complete the solder paste printing process before component placement.
The production line supports multi-dimensional customization to fit different production demands. For production capacity, equipment models can be adjusted to match different output speeds and production volumes. For product specifications, the line can be calibrated to adapt to different PCB sizes, component types and LED product structures. For workshop layout, the overall length and arrangement of the line can be adjusted to fit existing factory space. Additional auxiliary equipment such as conveyors, loaders and unloaders can also be added according to actual requirements.
Item | Specification |
|---|---|
Product Name | SMT Assembly Machine for PCB Production |
Brand | Wenzhan |
Model | Wz-smt-line |
Application | SMT PCB Assembly Production Line |
Included Equipment | Chip Mounter, Reflow Oven, AOI, PCB Printer |
Condition | New and used options available |
Size | Customizable |
Packaging | Wooden Case |
Supported Logistics Carriers | DHL, UPS, FedEx, TNT, EMS |
 |  |
This SMT assembly line adapts to multiple commercial production scenarios across different industries. For general PCB assembly, it supports the production of consumer electronics circuit boards, industrial control panels, power supply boards and automotive electronic components. For LED light production, it is suitable for manufacturing LED lamp panels, bulb assemblies, street light modules and various lighting products.
The line can operate stably in standard workshop environments, and can be configured for both long-term mass production and small-batch multi-variety production modes. It is applicable to electronic manufacturing factories, LED product manufacturers and other commercial users with surface mount production demands.
Routine preventive maintenance helps reduce unplanned downtime and extend the service life of production line equipment. For pick and place machines, regular cleaning and replacement of nozzles can reduce placement errors such as missing components, misplaced components and flipped components, which helps avoid finished board failure.
Electrical failures are common in SMT equipment, often caused by thermal stress from frequent equipment startup and shutdown. Paying attention to the operating status of power supplies, resistors, fuses, transformers, relay contacts, cables and plugs can help identify potential faults at an early stage.
Common routine maintenance tasks include regular inspection and cleaning of each equipment unit, maintenance and repair of exhaust fans, inspection of cooling systems and fans, removal of excess solder paste deposits, and timely replacement of perishable parts according to usage conditions. Establishing detailed maintenance logs for each piece of equipment can help identify operation patterns and arrange maintenance plans in advance, reducing the impact of maintenance on production schedules.
All equipment is packaged in solid wooden cases for transportation. Shock-absorbing filling materials are placed inside the cases to protect equipment components from impact during long-distance transportation. This packaging scheme adapts to both international sea freight and air freight scenarios.
Multiple international logistics carriers are supported, including DHL, UPS, FedEx, TNT and EMS. Customers can also designate their own freight forwarders for transportation arrangement. Both new and used equipment options are available for procurement; all used equipment undergoes full functional inspection and necessary maintenance before delivery to ensure normal operation. For customized production lines, the specific production and delivery cycle will be confirmed according to the final configuration scheme.
The standard configuration includes four core pieces of equipment: chip mounter, reflow oven, AOI inspection equipment and PCB printer. Auxiliary equipment such as conveyors, loaders, unloaders and solder paste mixers can be added according to actual production requirements.
Yes, the production line supports size customization. Customers can provide the maximum and minimum dimensions of their target PCBs, along with component specifications, and the equipment parameters will be adjusted to match the corresponding production requirements.
All equipment is packaged in solid wooden cases with internal shock-absorbing fillers. This packaging provides protection against impact, moisture and rough handling during long-distance overseas transportation, and meets the packaging requirements of both sea freight and air freight.
Yes, remote technical guidance for equipment installation, debugging and basic operation is provided for all orders. For enterprise customers with on-site service requirements, corresponding on-site service plans can be discussed and confirmed according to the project scale and location.
For detailed configuration quotations and customized solution consultation, you can submit your production requirements and workshop conditions to receive a targeted solution and quotation.
