About This Panasonic CM402 CM602 NPM 240C 240CN Nozzle

The 240C is one tip on the eight-nozzle head of a CM402, a CM602 or an NPM. Every position on that head picks its own part, and the designation on the nozzle decides what a position is meant to handle: the tip face seats on a chip, a resistor or a small capacitor, vacuum holds the part through the move, and the head presents it to the recognition camera before it goes down.

A tip is a wear part. Its face collects paste and flux mist, the bore slowly loads, and the seating collar hardens with heat cycles. What the line notices first is not a stop but a scatter - pickup misses on one position, parts that land rotated, or a recognition error that shifts as the head indexes.

Key Specifications & Panasonic Nozzle Part Number Mapping

Specifications

| Item | Value |

| --- | --- |

| Product Name | SMT Panasert CM402/CM602/NPM 8 Head 240C 240CN Nozzle |

| Type | SMT Machine Parts |

| Brand | Panasert |

| Condition | Original New |

| Package | Foam Package+Plastic BOX+Carton Box |

| Delivery | Ups,dhl,fedex,as Your Order |

| Port | Shenzhen |

Order terms

| Item | Value |

| --- | --- |

| Stock | large |

| Payment | L/C T/T D/P Western Union Paypal Money Gram And Others |

| Shipment | In three days |

| Warranty | 1 year |

Part numbers

| Reference | Number |

| --- | --- |

| Nozzle designations on this number | 240C / 240CN |

| Panasonic part number, 240CS tip | N610040853AA |

| Model carried on the order line | 240N NOZZLE |

One tip is the unit sold. Original new is one option and a copy is the other, both carried on this number; name your choice with the order.

8-Head Placement Compatibility & 240C Series Pickup Mechanics

An eight-nozzle head behaves as a row of separate positions rather than one mechanism. It picks eight parts in a pass, indexes, and sets them down; if a single tip cannot hold its part, that position misses while the other seven keep working, so the machine carries on producing and the defect comes back at a fixed interval.

That interval is the diagnostic. The number of good boards between misses points at a position, and the position points at a tip. Swap the suspect tip into another position and watch whether the fault follows it - if it does, the tip is the cause; if it stays put, the seat or the vacuum path is.

Match on the part number and on the type code, not on appearance. A 240C, a 240CN and a 240CS share a family outline without necessarily sharing a tip face, which is why a match is made from the machine family and the type code rather than from the outline.

Nozzle Inspection Standards, Packaging & One-Year Warranty Term

Check four things on a tip before it goes back into the head: the face for baked paste, the bore for a partial blockage, the seating collar for hardening or a hairline crack, and the number on the body against the position it is going into. A tip whose face has worn concave will keep missing however often it is cleaned, which is the point at which cleaning stops being the answer.

Packing runs in three layers - foam around the tip, a plastic box, then a carton - so the tip face is not resting against anything hard on the way. It leaves Shenzhen and travels by UPS, DHL or FedEx, whichever the order names; three days is the figure carried for the shipment.

One year is the period carried for this part. The order line states the model as 240N NOZZLE, which is worth quoting alongside the part number when a batch is confirmed against the head it is going into.
