Juki KE-2060 IC Head Z Axis Motor 40003255 SMT Part
About This Juki KE-2060 IC Head Z-Axis Motor
This motor moves the IC head of a Juki KE-2060 up and down. That head is the one carrying the larger devices - QFP, BGA and the odd shapes a chip shooter will not take - so the axis has to bring each of them down to the board and lift it away again, all shift long.
A tired motor is quiet at first. Parts sit down a shade high or a shade low, the head stops repeating to the same height, and placement that used to land inside tolerance begins to drift. None of that shows up as a motor fault at the line until somebody looks at the axis.
Two numbers belong to this part. 40003255 is the Juki parts number. TBL0-i 4603N1320E601 is what is stamped on the motor itself. Either one opens a match.
Key Specifications & Juki Part Number Mapping
Attribute region, recorded as it stands:
| Item | Value |
| --- | --- |
| Product Name | IC Z MOTOR 40003255 TBL0-i 4603N1320E601 |
| Model | 40003255 |
| Type | SMT Machine Parts |
| Condition | New, New/used |
| Package | Wooden Case |
| Delivery | Ups,dhl,fedex,as Your Order |
| Warranty Of Core Components | 3 Months |
| Port | Shenzhen |
| Stock | Large |
Description region, recorded as it stands:
| Item | Value |
| --- | --- |
| Name | IC Z MOTOR 40003255 TBL0-i 4603N1320E601 |
| Model | 40003255 |
| Condition | smt machine part |
| Stock | large |
| Payment | T/T before shipment |
| Shipment | on-time shipment |
| Delivery | fedex,ups,dhl,as required |
| Package | carton box with foam protect |
Two rows read differently between the blocks. Condition carries a pair of grades in the attribute region, new and new or used, and a category word in the description region. Packing is a wooden case in one block and a carton with foam in the other. Both readings are printed above as they appear on the page, and the one that governs your shipment is settled when the order is confirmed.
Z-Axis Motion Control & Placement Head Compatibility
Z is the vertical axis. On an IC head it takes the nozzle from travel height to the board, holds it while the part is set down, then lifts it clear before the head indexes on. The motor drives that travel, under the axis drive that the machine uses to command position.
Because the axis repeats the same short stroke for a whole shift, the part that wears is the one doing the repeating. A replacement is chosen on the number rather than on resemblance: two units can look alike in a photograph and still differ in mounting face, in shaft end and in cable connector.
Confirm the match from the number stamped on the motor coming off together with the machine model it came from. With those two, the fit is checked before an order is written.
Motor Condition Options, 3-Month Warranty & Packaging
Two condition entries are printed: one is new, the other is new or used. Neither is put forward here as the better buy. A new unit suits a head being rebuilt to a known baseline. A used one suits a line where the budget for that head is already fixed and a working part is what is wanted. Stock is listed as large, which is worth raising when the count is more than one.
The core components field carries three months. What that entry covers, and where the three months start, is worth having in writing before the order rather than afterwards.
Packing appears twice and the two entries disagree - a wooden case in one block, a carton with foam in the other. Ask which one applies to your shipment, more so where the motor is going by air.
Voltage, power rating, torque, encoder resolution, shaft size and mounting dimensions are not printed anywhere on this number, and they are not quoted here. They come off the motor being replaced, and they are what the fit is checked against.
Frequently Asked Questions On The 40003255 Z Motor
Q1: Which machine does this motor serve?
A: The IC head of a Juki KE-2060, the head that places QFP, BGA and odd-shaped devices.
Q2: What are the two numbers for?
A: 40003255 is the Juki parts number. TBL0-i 4603N1320E601 is stamped on the motor.
Q3: Is the motor new or used?
A: Both entries are printed, new and new or used. Say which you want when you ask.
Q4: What are the electrical and shaft specifications?
A: They are not printed on this number. Read them off the motor being taken off.
Q5: How does it ship?
A: Two packings are listed, a wooden case and a carton with foam. The one for your shipment is confirmed with the order.
Q6: How much stock is there?
A: It is listed as large. Anything above a single unit is worth raising at inquiry.
Inquiry & Juki SMT Motor Replacement Support
- Company: WEN ZHAN Technology
- Tel / WhatsApp: +86 18823383970
- E-mail: wenzhanhucai@163.com
Send the machine model, the number stamped on the motor coming off, the quantity and the condition you want, and the match plus the price come back against those details.
