| MOQ: | 1pcs |
| Price: | 7042~14082$ |
| Standard Packaging: | 1.wooden case 2.As your order |
| Supply Capacity: | 10 Piece/Pieces per Week |
High Professional Vaccume Reflow Oven Circuit Reflow Oven Reflow Oven Manufacturer From China
The domestic reflow soldering machine is a crucial piece of equipment in the electronics manufacturing industry, primarily used for soldering surface mount devices (SMDs) onto printed circuit boards (PCBs). This machine ensures reliable electrical connections and is essential for producing high-quality electronic assemblies.
| RF-8820PC-LF | RF-8810PC/LS-LF | RF-8830PC/LS-LF | |
| Dimension | 5000×1200×1550mm | 4600×1000×1550mm | 4600×1500×1550mm |
| Weight | 1800kg | 1200kg | 1600kg |
| Number of heating zone | Top 8/Bottom 8 | ||
| Length of heating zone | 3160mm | 2800mm | 2800mm |
| Cooling quantity | Up 2/Bottom 2 | Up 1/Bottom 1 | Up 1/Bottom 1 |
| Air discharge requirement | 10m³/min×2 | ||
| Power requirements | 3 phase 380V 50/60Hz | ||
| Starting power | 36KW | 32KW | 48KW |
| Operating power | 7KW | 6.5KW | 8KW |
| Heating time | Approx: 20min | ||
| Temperature control range | Room temp-320°C | ||
| Temperature control Mode | PID closed-loop control with SSR drive (computer + PLC) | ||
| Temperature control precision | ±1°C | ||
| Temperature deviation On PCB | ± 2°C | ||
| Abnormal alarm | Ultra high temperature or low temperature alarm | ||
| Maximum width of PCB | 50-500mm | 50-450mm | 50-600/700/800mm |
| Guide rail width range | 50-400mm | 50-370mm | 50-500/600/700mm |
| PCB element height | Top 30mm Bottom 25mm | ||
| Transportation direction | L-R (Option: R-L) | ||
| Transportation speed | 0-1800mm/min | ||
| Transportation height | 900±20mm | ||
| Transport guide rail fixation | Front end fixed (Option: Back end fixed) | ||
| Cooling mode | Force wind cooling | ||
| PCB transport mode | Chain +Ribbon | Chain (Chain optional) | Chain (Chain optional) |
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
We have full range of SMT pick and place machine For FUJI,JUKI,SAMSUNG,YAMAHA, and so on,feeder,nozzle,smt pick and place machine,PCB Conveyor,
cylinder,and vibration feeder,anything you need ,just tell me!
The main brand is Fuji YAMAHA Samsung SONY heavy machine
1. SMT lubricating oil
2. SMT parts
3. Nozzle and feeder
4. SMT belt and other parts in the machine
Video
Video
Video
Video
Video
Video
|
|
