SMT Chip Mounter JUKI RS1R RS-1 RS SMT Pick And Place Machine for PCB Assembly Machine

SMT Chip Mounter JUKI RS1R RS-1 RS SMT Pick And Place Machine for PCB Assembly Machine

Quantity:




Inquire Add to Basket

JUKI RS1R SMT pick and place machine PCB assembly pick and place machine JUKI RS-1 SMT mounter

Product Details

Highlight:

JUKI RS1R SMT pick and place machine

,

PCB assembly pick and place machine

,

JUKI RS-1 SMT mounter

Product Name: JUKI RS-1 SMT Pick And Place Machine

Brand: JUKI

Model Number: RS-1

Component Hight: 25mm

Component Size: 0201*1(British System：008004）～74mm /50×150mm

Type Of Component Mounting: Up To 112 Types (when RF Feeder Is In Use)

Warranty: 1 Year

Component Mounting Speed: 42,000CPH

Package: Wooden Case

Delivery: Ups,dhl,fedex,as Your Order

Product Description

Detailed Specifications And Features

SMT Assembly Machine Chip Mounter JUKI RS-1 SMT Pick And Place Machine

The RS-1 Chip Mounter is a sophisticated machine designed for the efficient assembly of surface mount devices (SMDs) onto printed circuit boards (PCBs). This equipment plays a critical role in the electronics manufacturing process, ensuring high precision and speed in component placement.

Process Overview:

The operation of the RS-1 Chip Mounter begins with the preparation of the PCB, which is securely positioned on the machine's work table. The mounter is equipped with advanced vision systems that facilitate precise alignment between the components and their designated pads on the PCB.

Once the PCB is ready, the RS-1 uses a pick-and-place mechanism to accurately pick SMDs from a feeder system. The machine employs a high-speed robotic arm that moves swiftly to place the components onto the PCB. The vision system continuously monitors the placement process to ensure that each component is positioned correctly.

After component placement, the PCB is typically sent to a reflow oven for soldering, where the solder paste applied during a previous stage melts and solidifies, securing the components in place. The RS-1 Chip Mounter is known for its ability to handle a wide variety of component types and sizes, making it versatile for different production needs.

Applications:

Consumer Electronics: Used in the assembly of smartphones, tablets, and other electronic devices that require compact and precise component placement.
Automotive Electronics: Employed in the production of automotive control units and infotainment systems, where reliability and accuracy are essential.
Medical Devices: Utilized in manufacturing PCBs for medical equipment, ensuring adherence to strict quality and safety standards.
Industrial Automation: Applied in the assembly of control systems for industrial machinery, where efficient and accurate component placement is crucial.

High speed module mounter
Machine Name			RS-1
Transfer Pattern			Standard	Import and export 150mm extension	Import and export 250mm extension
Substrate Size	Min		50*50mm
	Max	1 buffer time	650*370mm(Primary splint)
			950*370mm(Double splint)	1,100*370mm(Double splint)	1,200*370mm(Double splint)
		3 buffer time	360*370mm	500*370mm	600*370mm
Component Hight			25mm
Component Size			02011(British system:008004)～74mm /50150mm
Component Mounting Speed			42,000CPH
Type of component mounting			Up to 112 types (when RF feeder is in use)
