Samsung CP45 CN220 Nozzle J9055139B SMT Part
About This Samsung CP45 CN220 SMT Nozzle
CN220 is the tip that sits on a CP45 or CP45FV placement head, and J9055139B is the number it travels under. It is a single nozzle sold on its own: one tip, one box, ready for the spare-parts drawer and fitted when the position it serves begins to miss.
A head rarely fails all at once. One tip goes first and the symptom stays local - a part dropped a fraction off centre, a run of misses on one position, a placement the camera reads as rotated. Swapping one tip is the cheapest test a line has.
Key Specifications & CP45 CN220 Ordering Details
Specifications
| Item | Value |
| --- | --- |
| Product Name | SAMSUNG CN220 NOZZLE |
| Brand | SAMSUNG |
| Type | SMT Machine Parts |
| Condition | New, Original And Copy New |
| Warranty | 3 Months |
| Package | Standard Package (plastic Bag+carton Box) |
| Delivery | Fedex,ups,dhl,as Required |
Part number
| Reference | Number |
| --- | --- |
| Samsung part number | J9055139B |
| Nozzle designation | CN220 |
CP45 Placement Head Compatibility & CN220 Tip Function
The head carries vacuum down to the tip and holds the component there while it travels and descends. Anything that goes wrong afterwards - a part slipping, one landing crooked, one the camera refuses - begins at the seal between the tip face and the component.
Fitting is mechanical work. Seat the tip, confirm it sits square, then check the height. A tip that is not fully seated behaves like a worn one, which is why a fresh tip is fitted and checked before the old one is blamed for something else.
What wears is the part you would expect it to be. The face dulls against paste and board, and the bore gradually picks up flux. Neither shows from outside, so a replacement is ordered against the number on the body rather than against the look of the thing.
Nozzle Condition Options, Quality Inspection & 3-Month Warranty
Three condition entries are offered on this part: new, original, and copy new. New is an unused tip; original is the machine maker's own part; copy new is a fresh aftermarket tip built to the same form. They are options rather than a ranking - which one suits depends on whether the machine is being held to factory specification or the tip is treated as a consumable.
Before fitting, check three things: the tip face for a polished or chipped edge, the bore held up to a light, and the number on the body.
It goes out bagged and then boxed, which is enough for a single tip, and dispatch is by FedEx, UPS or DHL.
Three months is the period attached to this part.
Frequently Asked Questions On The Samsung CN220 Tip
Q1: Which head does this tip fit?
A: The CP45 and the CP45FV placement head.
Q2: Is a set required, or is one tip enough?
A: One tip is the unit here; take as many as the positions you are covering.
Q3: What separates new, original and copy new?
A: Unused, the machine maker's own part, and a fresh aftermarket tip in the same form.
Q4: How is the right tip confirmed?
A: From the number J9055139B on the body, together with the head it goes into.
Q5: What is the cover period?
A: Three months.
Q6: How is it sent?
A: In a plastic bag and a carton, by FedEx, UPS or DHL.
